Alu-Pro 2500 CLS S SR
DB/TUN nummer: 2166257
EAN no.: 5701747056828
Medium version of the popular ALU-PRO 2500. ALU-PRO 2000 Medium w / standard support plate and slide rails are equipped with the popular ergonomic handles, the angle of which causes the position of arms and hands to be optimal and the load on the hand, elbow and shoulder joint to be minimized. The handles can be adjusted from 1170-1540 mm, allowing them to be set to the optimal working height and position. * Standard support plate * Ergonomic and adjustable handles * Slide rails
Specifications
- DB/TUN Number
- 2166257
- Recommended use
- PRO
- Warranty
- 5 år
- Country of origin
- China
- W (mm)
- 500
- H (mm)
- 1530
- Support plate B (mm)
- 220
- Support plate L (mm)
- 335
- Load capacity (kg)
- 250
- Dead weight (kg)
- 15
- Wheel Size
- 3.00 x 4/4
- Rim
- Plastic
- Bearing
- Roller bearings
- Hub Ø (mm)
- 20
- Hub L (mm)
- 75
- Wheel Type
- Pneumatic
- Material
- Alu
- Colour
- Black , Yellow , Silver
- Handle
- Plastic, grey
- Quantity per pallet
- 8
- Assembly
- Mounted
Description
Medium version of the popular ALU-PRO 2500. ALU-PRO 2000 Medium w / standard support plate and slide rails are equipped with the popular ergonomic handles, the angle of which causes the position of arms and hands to be optimal and the load on the hand, elbow and shoulder joint to be minimized. The handles can be adjusted from 1170-1540 mm, allowing them to be set to the optimal working height and position. * Standard support plate * Ergonomic and adjustable handles * Slide rails
Download materials
| Name | Download | File type | |
|---|---|---|---|
|
145682.jpg | 1491 KB | .jpg |
|
145682.pdf | 107 KB |
